DAYSENSOR / Калибратор динамометрического ключа

The ZM2DW force sensor F, M utilizes independent wheatstone full bridge for each axis which provides mV/V output proportional to the applied force and requires no mathematical manipulation. Typical applications for this type of transducer are for example force exertion control in robotics, automotive crash testing, industrial test benches, grinding force control, actuator operating force measurement,etc.

Compact size

The ZHKY2050 is a compact non-contact type torque sensor ideal for low torque applications with maximum of only 5N·m. The ZHKY2050 can still handle up to 8000RPM so it is for systems that require high speed.

The KWR46 series sensor is a small-size compact six-axis force sensor. It has characristics with light weight and small volumn. Its measuring range is around 50N to 200N, and could be customized as your needs. Our product has high anti-overload protection ability, it can withstand 300% overload.The small-size sensor widely used in scientific research and medical testing fields. For this series model small volumn that it can’t be embedded in circuit board moduel, so we will provide a signal acquisition box according to the communication protocol version you need.

Статический датчик крутящего момента — это прибор, который преобразует деформацию, возникающую при крутящем моменте, в электрический сигнал с линейной зависимостью согласно принципу тензометрического измерения сопротивления.
Изделие обладает зрелой технологией производства, полным ассортиментом, широким диапазоном, высокой точностью, стабильной и надежной работой.
Широко используется в испытательных машинах, системах измерения статического крутящего момента и других тестовых системах.

The ZMNJ is a non-rotating type torque transducer that converts a torsional mechanical input into an electrical output signal. The ZMNJ can be used in both clockwise and counterclockwise direction ranging from 1Nm up to 200Nm. The sensor is used in static and non-rotating torsion measure applications.

Nickel plated alloy steel

For static, non-continuous torque measurement

0.1-500N.m IP66 dynamic torque sensor FA604 is a model of our brand FIBOS FA6-Series, it belongs to torque sensor, FA604 can be used to measure torque force 0.1N.m, 0.2N.m, 0.3N.m, 0.5N.m, 1N.m, 2N.m, 3N.m, 5N.m, 10N.m, 20N.m, 30N.m, 50N.m, 100N.m, 200N.m, 300N.m and 500N.m capacity, its Creep(30min) and Repeatability both same ≤0.1%F.S., its Non-linearity and Hysteresis both ≤0.2%F.S..

Suitable for dynamic, bearing, torque wrench and other testers

Suitable for dynamic, bearing, torque wrench and other testers

1、Static torque sensor is a kind of sensor used to measure the torque of a stationary or slowly rotating object.
2、The flange mounted sensor is connected with a load transfer device, which can output voltage or current signals.
3、It is used for static discontinuous rotation, non-standard customization, anti-interference signal stability, and is widely used in static torque testing systems such as testing machines, torque wrenches, steering gears, electric actuators, valves, transmissions, and hydraulic pressure.
4、Small size, light weight and convenient installation and use.
5、 High detection accuracy, good stability and strong anti-interference ability.

The KWR63 series is a small circle volumn Multi Axis load cell, which is close to the outer diameter of the end of most cooperative robots. The material is aluminum alloy, and the f/t sensor has the characteristics of high overload, high rigidity and high sensitivity.It support wide communication protocol, such as RS422, RS485, Industrial Ethernet, USB, CAN,etc.
