For static, non-continuous torque measurement

5-500N.M IP66 Dynamic Torque Sensor Force Torque Sensor FA603 is a model of our brand FIBOS FA6-Series, Dynamic Torque Sensor Force Torque Sensor FA603 can be used to measure dynamic torque force ranges from 5N.m,10N.m,20N.m,50N.m,100N.m,200N.m and 500N.m capacity, its Rated output range is 1.0~1.5mV/V, its Zero Balance range is ±0.01mV/V.

• Range: 0-10000N.m
• Sensitivity: 1.0-2.0mV/V
• Nonlinear Accuracy 0.3% F.S.
• Repeatability 0.1% F.S.
• Material: Alloy Steel Nickel Plated
• Force measurement direction: rotational force
• Product name: Static torque sensor DYJN-101 series
• Can be customized on request

ZMDN is a high-precision rotarting torque sensor. The max rotating speed that the sensor can accept is 3000rpm. The output signal of ZMDN is from 1.0-1.5mv/v. Analog transmitter 4-20mA, 0-5V, 0-10V is optional.

Stainless steel body

1、Static torque sensor is a kind of sensor used to measure the torque of a stationary or slowly rotating object.
2、The flange mounted sensor is connected with a load transfer device, which can output voltage or current signals.
3、It is used for static discontinuous rotation, non-standard customization, anti-interference signal stability, and is widely used in static torque testing systems such as testing machines, torque wrenches, steering gears, electric actuators, valves, transmissions, and hydraulic pressure.
4、Small size, light weight and convenient installation and use.
5、 High detection accuracy, good stability and strong anti-interference ability.

The ZMNJ is a non-rotating type torque transducer that converts a torsional mechanical input into an electrical output signal. The ZMNJ can be used in both clockwise and counterclockwise direction ranging from 1Nm up to 200Nm. The sensor is used in static and non-rotating torsion measure applications.

Nickel plated alloy steel

The ZHKY2050A is a series of non-contact type torque sensors ideal for testing and measurement of industrial rotating machines. Designed to be small and rugged it can easily be installed in a variety of industrial applications. The sensor can output torque and speed for measuring power exerted by the attached rotating machine.

1、Static torque sensor is a kind of sensor used to measure the torque of a stationary or slowly rotating object.
2、The flange mounted sensor is connected with a load transfer device, which can output voltage or current signals.
3、Static torque sensors can be used in various industrial fields, such as electric screwdrivers, torque wrenches, wind turbines and so on.
4、Small size, light weight and convenient installation and use.
5、 High detection accuracy, good stability and strong anti-interference ability.

• Range: 0-3000N.m
• Sensitivity: 1.0-2.0mV/V
• Nonlinear Accuracy 0.3% F.S.
• Repeatability 0.1% F.S.Material: Alloy Steel Nickel Plated
• Force measurement direction: rotational force
• Product name: Static torque sensor DYJN-103 series
• Can be customized on request

100,200,1000,2000,3000N.m Or Customized Static Torque Sensor Force Torque Sensor FA625B belongs to FA625 which belongs to Static Torque Sensor of Force Torque Sensor category, FA625B can be used to measure Static Torque force 100N.m,200N.m,1000N.m,2000N.m and 3000N.m or customized capacity, its Cable size is ⌀6x4500mm or can be customized.

The ZHKY2050B is a compact slip ring type torque sensor ideal for high torque applications. This sensor is designed to be rugged so that it can handle a maximum of up to 500N·m at 8000RPM.

• Range: 0-150N.m
• Sensitivity: 2.0mV/V
• Nonlinear Accuracy 0.05% F.S.
• Repeatability 0.05% F.S.
• Material: Aluminum Alloy/Alloy Steel Nickel Plated
• Force measurement direction: rotational force
• Product name: Static torque sensor DYJN-104 series
• Can be customized on request
