Rated Load: >300kg
Accuracy : 30000D
Type : weighing indicator, Platform scale indicator
Shipping: Support Sea freight · Land freight
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Model Number: | B08 | Power Supply: | -7mV ~ 12.8mV |
| Display Type: | 6-digit 20mm LED or 25mm LCD with backlight | Display: | 6-digit 20mm LED or 25mm LCD with backlight |
| Accuracy class: | OIML III | Input voltage: | -7mV ~ 12.8mV |
| Resolving: | display15000, internal code 1000000 | Excitation voltage: | DC3.3V |
| Functions: | accumulate, hold, animal weighing, check, sort |
Rated Load: >300kg
Accuracy : 30000D
Type : weighing indicator, Platform scale indicator
Shipping: Support Sea freight · Land freight
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Model Number: | LP7512 | Power Supply: | -10mV ~ 19.5mV |
| Display Type: | 6-digit 20mm LED or 25mm LCD with backlight | Display: | 6-digit 20mm LED or 25mm LCD with backlight |
| Accuracy class: | OIML III | Input voltage: | -10mV ~ 19.5mV |
| Resolving: | display50000, internal code 2000000 | Excitation voltage: | DC5V |
| Power supply: | AC110/240V 50/60Hz DC9V or built-in 6V/4Ah lead acid battery |
Features
* Compatible with all functions of model XK3190-A9+
* High precision A/D conversion with readability 1/30000
* Non-linearity correction, calibration tolerance correction
* Auto change division among 3 different weighing ranges set up by user
* Password management and time power off function
* Set up print function for auto/manual, no condition/ under condition, daily/ stored statistics report printing
* Standard RS232 communication interface with selectable baud rate and communication method (RS422/RS485 optional)
* Standard scoreboard interface with current loop(20mA)method and standard parallel printer interface
* Able to print any parameter of indicator for saving and referring.
* Hardware detection and voltage of load cell output displaying function
Industrial automation, medical, 3C, agriculture and animal husbandry, assembly measurement and various industrial system testing
| Customized support: | OEM | Place of Origin: | Zhejiang, China |
| Brand Name: | Santwell | Model Number: | LP7553 |
| Power Supply: | -6mV ~ 19.5mV | Display Type: | 6-digit 50mm LED or LCD with backlight |
| Accuracy class: | OIML III | Resolving: | display50000, internal code 2000000 |
| Excitation voltage: | DC3.3 V | Power supply: | AC110/220v 50/60Hz |
| Warranty: | 1year | Customized support: | OEM, ODM, OBM |
| Place of Origin: | Zhejiang, China | Brand Name: | santwell |
| Model Number: | A12E | Power Supply: | 6V/4AH |
| Display Type: | LCD/LED | Accuracy: | Gradelll,n=3000 |
| Sample Rate: | 10 times/second | Load cell sensitivity: | 1.5~3mV/V |
| Scale interval: | 1/2/5/10/20/50 for option | Scoreboard interface (optional): | In serial output mode:current loop signal, transmission distance≤50m |
| Communication interface (optional): | RS232C | Power supply: | Battery DC6V/4AH |
| Operating temperature/humidity: | 0-40℃;≤90%RH | Baud rate: | 1200/2400/4800/9600 optional |
Industrial automation, medical, 3C, agriculture and animal husbandry, assembly measurement and various industrial system testing
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Model Number: | LP7515 | Power Supply: | -3mV ~ 12mV |
| Display Type: | 6-digit 20mm LED with backlight | Accuracy class: | OIML III |
| Resolving: | display50000, internal code 2000000 | Excitation voltage: | DC3.3 V |
| Power supply: | 3 AA-size batteries,or DC6V |
| Customized support: | OEM | Place of Origin: | Zhejiang, China |
| Brand Name: | Santwell | Model Number: | LP7512 |
| Power Supply: | -10mV ~ 19.5mV | Display Type: | 6-digit 20mm LED or 25mm LCD with backlight |
| Display: | 6-digit 20mm LED or 25mm LCD with backlight | Accuracy class: | OIML III |
| Input voltage: | -10mV ~ 19.5mV | Resolving: | display50000, internal code 2000000 |
| Excitation voltage: | DC5V | Power supply: | AC110/240V 50/60Hz DC9V or built-in 6V/4Ah lead acid battery |
| Warranty: | 1 year | Customized support: | OEM, ODM |
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Model Number: | XK315A1GB-3 | Housing: | Stainless steel |
| Display: | 6-digit 20.2mm green LED | Dimensions: | 260*222*161mm |
| Weight: | 2.2kg | Inside battery: | 6V 2.8AH |
| Applications: | Electronic platform scale, weighing scale, etc. |
| Customized support: | OEM, ODM | Place of Origin: | Zhejiang, China |
| Brand Name: | Santwell | Model Number: | XK3190-A9+ |
| Power Supply: | DC8V | Display Type: | 7 bits LED ,7 status indications |
| Model: | A9/ A9P | Input signal range: | 1mV~24mV |
| Load cell Excitation: | Dc 8V | Max. load cell connection: | 8 at 350 ohm |
| Display: | 7 bits LED ,7 status indications | Standard interface: | RS232C , Scoreboard at 20mA current loop Parallel printer |
Industrial automation, medical, 3C, agriculture and animal husbandry, assembly measurement and various industrial system testing
| Warranty: | 3 years | Place of Origin: | Zhejiang, China |
| Brand Name: | Santwell | Model Number: | ST110 |
| Power Supply: | -3.6 mV/V ~ 3.6 mV/V | Display Type: | Dual-row LED Display |
| Sensor Type: | Resistance Strain Sensor | Decimals: | 0, 0.0, 0.00, 0.000, 0.0000, 0.00000 |
| On-off input voltage: | DC24V | On-off input current: | 4-6mA |
| Division value: | 1, 2, 5, 10, 20, 50 | Max weighing display range: | 999999 |
| Sensor excitation voltage: | DC5V, Four 350Ω Sensors Can be Connected in Parallel | A/D switching speed: | ≤100 times / second |
| Zero Drift: | ≤10μV/°C |
